CL-410 - Centre Lathe

Ø410 x 1000mm Turning Capacity - Ø58mm Spindle Bore

Includes Digital Readout System & Quick Change Toolpost

L600D 1 of 38

Left View 2 of 38

2 Axis Digital Readout 3 of 38

Chuck Guard With Micro 4 of 38

Headstock Controls 5 of 38

Spindle Speed Levers 6 of 38

Gearbox Levers 7 of 38

Thread and Feed Chart 8 of 38

Quick Change Toolpost 9 of 38

Auto Lubrication Pump 10 of 38

Saddle Safety Guard 11 of 38

Saddle Safety Guard Shown Open 12 of 38

Compound Slide 13 of 38

Leadscrew Covers 14 of 38

Thread Chasing Dial 15 of 38

Spindle Engagement Lever 16 of 38

5 Position Adjustable Length Stop 17 of 38

Compound Slide Dial in Metric Mode 18 of 38

Compound Slide Dial in Imperial Mode 19 of 38

Cross Feed Dial In Metric Mode 20 of 38

Cross Feed Dial In Imperial Mode 21 of 38

Saddle Dial 22 of 38

Compound Angle Scale 23 of 38

Saddle Controls 24 of 38

Hardened & Ground Bedways 25 of 38

58mm Spindle Bore 26 of 38

Removable Gap Bed 27 of 38

Fixed Steady With Roller Guides 28 of 38

Travelling Steady With Roller Guides 29 of 38

LED Worklight & Coolant Hose 30 of 38

LED Worklight Close Up 31 of 38

Tailstock 32 of 38

Tailstock Quill Graduations 33 of 38

Tailstock with Adjustable Horizontal Movement 34 of 38

Tailstock Dial in Metric Mode 35 of 38

Tailstock Dial in Imperial Mode 36 of 38

Foot Brake 37 of 38

Main Switch 38 of 38

HAFCO-METALMASTER

On Sale

Order Code: L600D

ex-gst

inc-gst

^$ 16,750.00

^$ 18,425.00

^$ 15,750.00

^$ 17,325.00

415V / (NO PLUG)
1 Year Warranty

Add to Cart

Enquire

Price Match

Compare

Wishlist

Delivery & Pickup Availabilities

Description Specifications Compare Accessories Related Downloads Spare Parts

Description

CL-410 - Centre Lathe

Ø410 x 1000mm Turning Capacity - Ø58mm Spindle Bore

Includes Digital Readout System & Quick Change Toolpost

Features

2 axis digital readout system
Quick change toolpost
Triple bearings supporting headstock spindle
Adjustable taper roller bearings providing spindle accuracy
Precision 'V'-beds & headstock gears are all hardened & ground
Automatic lubrication pump for saddle & cross slides
One piece cast iron base increases rigidity
Overload protection on drive motor and coolant system
Universal enclosed gearbox incorporating metric & imperial thread capabilities
Inching button incorporated on the control panel for convenient spindle speed selection
Foot operated spindle brake with safety cut out switch
300mm wide induction hardened heavy duty cast iron bed
Removable gap bed allowing work piece to swing up to 640mm
Chuck guard fitted with safety micro switch
Powered longitudinal and cross feeds
Adjustable 5 position length-stop mechanism for accurate repetitive operation
Dual calibrated dials incorporating metric & imperial graduations
Coolant system with flexible hose enabling operator to manipulate flow direction
Oil sight glass for head stock and gearbox
Low voltage halogen work light
D1-6 camlock spindle for quick chuck removal
12 spindle speeds from 25-2000rpm
Large 58mm spindle bore
5.5kW / 7.5HP 415V main motor

Includes

2 axis digital readout system
Quick change toolpost
250mm 3-jaw chuck with reverse jaws
250mm 4-jaw chuck
Fixed Steady with roller bearings
Travelling steady with brass guides
Concertina leadscrew covers
Faceplate
Dead centres
Thread chasing dial
Foot brake
Coolant system
Work light
Rear splash guard
Spindle reducing bush

Specifications

Compare Product Range

Specifications

ORDER CODE	L600D
MODEL	CL-410
(mm)Swing Over Bed	410
(mm)Distance Between Centres	1000
(mm)Spindle Bore	58
(mm)Swing In Gap	640
(mm)Swing Over Cross-slide	224
Digital Readout System Fitted	Yes
Quick Change Toolpost Fitted	Yes
Leadscrew Covers Fitted	Yes
Coolant System	Yes
(mm)Tool Height To Suit	25
(mm)Centre Height	205
Spindle Nose Size or Type	D1-6 Camlock
(mm)Bed Width	300
(MT)Headstock Spindle Taper	6
(MT)Tailstock Taper	4
(mm)Cross Slide Travel	290
(mm)Compound Slide Travel	128
Leadscrew Type	Metric
(mm/rev)Metric Cross Feed (X-Axis)	0.014 - 0.784
(mm/rev)Metric Longitudinal Feed (Z-Axis)	0.031 - 1.70
(No. / mm)Metric Thread Steps & Pitch	41 (0.1 - 14)
(No. / TPI)Imperial Thread Steps & TPI	60 (2 - 112)
(mm)3 Jaw Chuck Diameter	250
(mm)4 Jaw Chuck Diameter	250
(No. / rpm)Spindle Steps / Speeds	12 (25 - 2000)
(kW / hp)Motor Power	5.5 / 7.5
(V / amp)Voltage / Amperage	415
(kg)Nett Weight	1850
