BODOR i7 CE 12kW - Compact Sheet Fiber Laser Cutting

3048 x 1524mm Table
Includes Door-open Protection
Overview
Bodor i series increases productivity of your production line without requiring much space. The system has been designed to take up as little floor space as possible.
The fully enclosed design leads to more economical processing and faster performance, with a much lower power consumption.
Features
  • Active obstacle avoidance system - BodorGenius, Bodor’s intelligent laser head, uses sensors and algorithms to detect potential obstacles like tilting parts and automatically avoids a potential collision. It largely ensures the stability as well as operating efficiency in the cutting process.
  • Lightning piercing - The technology offers rapid, precise piercing with reduced time. It features monitored processes for efficiency, automatic focus adjustment for seamless piercing, and integration with Bodor Genius. This enables quick piercing in sync with the cutting head's movement, optimizing operations for medium-thick plates without additional time or motion.
  • Intelligent remnant layout - To achieve maximum material utilization, all you need to do is uploading pictures of the remnant to the control system with your mobile phone. C series is able to automatically finish positioning as well as nesting. The higher the percentage of utilization, the more economical the process. Enjoy the benefits of significantly increased cost savings.
  • Anti-burning mineral casting - Bodor's newly developed anti-burning casting material provides numerous advantages in slag removal, operations, and modular design. When in use, material residue automatically separates from the anti-burning plate, largely lowering maintenance costs and offering better durability. Its lightweight structure as well makes it easy to replace.
  • Auto Focus - Applicable to various focal lengths, which are controlled by machine tool control system. Focal point will be automatically adjusted in cutting process to achieve the best cutting effect of different thicknesses sheets metal.
Includes
  • Bodor’s Genius: cutting head with programmable motorised lens and Collision Protection
  • Bodor Power: is the backbone of any laser cutting system, and BodorPower takes it to the next level. This original laser source is the key to Bodor’s high power processing (up to 60kW). It ensures longer lifespans, safer operations, and superior cutting results of every Bodor cutting machine.
  • BodorThinker: serves as the intelligent core of Bodor’s laser cutting solutions. This control system integrates seamlessly with MES and ERP systems, facilitating automated production process management and information exchange through standardised communication protocols.
  • Door-open Protection
  • Cutting view camera
  • 21" LCD Touch screen
  • Local Service and Support
  • *12 month warranty on machine parts & labor
  • Commissioning & Testing Included (Metro Areas)
  • Comprehensive Operator Training Included (Metro Areas)
  • *Five year factory warranty on - Bodor Thinker Control System, Bodor Power Laser Source, Bodor Genius Laser Head.
Optional Accessories
  • MMF-6L - Laser Fume Extraction 7.5kW (W2724)
Compare Product Range Compare Selected
  • Compare:
  • Wishlist:
  • ORDER CODE
  • (Type)MODEL
  • (kW)Laser Power
  • (mm)Cutting Table Capacity
  • (G)Max acceleration
  • (mm)Positioning accuracy
  • (mm)Repeatability
  • (m/min)Compound Rapid speed
  • Laser Type
  • Laser Source
  • Laser Head
  • Control System
  • Door-open Protection
  • (kg)Max. Table Load Capacity
  • Active Obstacle Avoidance
  • One-Click Processing
  • Intelligent Remnant Layout
  • Lightning Piercing
  • High Speed Cutting Expert Database
  • Auto Focus Laser Head
  • Automatic Nozzle Change
  • Anti-Burning Mineral Casting Plate
  • Nesting Software
  • (Type)Drawing File
  • Laser Scanning Cutting
  • Transfer Table - Motorised
  • Bevel Cutting
  • (kg)Nett Weight
  • (mm)Machine Size
  • (ex-gst)Pricing
  • (inc-gst)
  • L78100
  • Compare
  • Wishlist
  • L78100
  • i5 3kW
  • 3
  • 1000 x 1500
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 250
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 2000
  • 2980×2220×1970
  • Please Call
  • Please Call
  • ADD TO CART
  • L78101
  • Compare
  • Wishlist
  • L78101
  • i5 6kW
  • 6
  • 1000 x 1500
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 250
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 2000
  • 2980×2220×1970
  • Please Call
  • Please Call
  • ADD TO CART
  • L78102
  • Compare
  • Wishlist
  • L78102
  • i6 3kW
  • 3
  • 2000 x 1000
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 400
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 3110
  • 4049×1955×2230
  • Please Call
  • Please Call
  • ADD TO CART
  • L78103
  • Compare
  • Wishlist
  • L78103
  • i6 6kW
  • 6
  • 2000 x 1000
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 400
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 3110
  • 4049×1955×2230
  • Please Call
  • Please Call
  • ADD TO CART
  • L78104
  • Compare
  • Wishlist
  • i8102
  • i7 CE 3kW
  • 3
  • 3048 x 1524
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 900
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 4980
  • 4955×2320×2200
  • Please Call
  • Please Call
  • ADD TO CART
  • L78105
  • Compare
  • Wishlist
  • L78105
  • i7 CE 6kW
  • 6
  • 3048 x 1524
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 900
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 4980
  • 4955×2320×2200
  • Please Call
  • Please Call
  • ADD TO CART
  • L78106
  • Compare
  • Wishlist
  • L78106
  • i7 CE 12kW
  • 12
  • 3048 x 1524
  • 1.5
  • ±0.05
  • ±0.03
  • 91
  • Fiber Lsser
  • BodorPower
  • BodorGenius
  • BodorThinker
  • Yes
  • 900
  • Yes
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • No
  • Yes
  • Yes -Compatible with Tekla
  • G Code, DXF, DWG
  • Optional
  • Optional for i6 &i7 only
  • No
  • 4980
  • 4955×2320×2200
