BODOR i6 CE 3kW Compact Sheet Fiber Laser Cutting

Home CNC Fiber Laser Cutting Compact-Sheet-Cutting L78102

BODOR i6 CE 3kW - Compact Sheet Fiber Laser Cutting

2000 x 1000mm Table

Includes Door-open Protection

L78102 1 of 6

Compact CNC Laser Cutter Overview | bodor I Series | 2 of 6

Anti burning mineral casting plate 3 of 6

Intelligent remnant layout 4 of 6

Active obstacle avoidance 5 of 6

Lightning piercing 6 of 6

BODOR

Order Code: L78102

ex-gst

inc-gst

^$ 113,450.00

^$ 124,795.00

1 Year Warranty

Add to Cart

Enquire

Price Match

Compare

Wishlist

Delivery & Pickup Availabilities

Description Specifications Compare Accessories Downloads

Description

BODOR i6 CE 3kW - Compact Sheet Fiber Laser Cutting

2000 x 1000mm Table

Includes Door-open Protection

Overview

Bodor i series increases productivity of your production line without requiring much space. The system has been designed to take up as little floor space as possible.
The fully enclosed design leads to more economical processing and faster performance, with a much lower power consumption.

Features

Active obstacle avoidance system - BodorGenius, Bodor’s intelligent laser head, uses sensors and algorithms to detect potential obstacles like tilting parts and automatically avoids a potential collision. It largely ensures the stability as well as operating efficiency in the cutting process.
Lightning piercing - The technology offers rapid, precise piercing with reduced time. It features monitored processes for efficiency, automatic focus adjustment for seamless piercing, and integration with Bodor Genius. This enables quick piercing in sync with the cutting head's movement, optimizing operations for medium-thick plates without additional time or motion.
Intelligent remnant layout - To achieve maximum material utilization, all you need to do is uploading pictures of the remnant to the control system with your mobile phone. C series is able to automatically finish positioning as well as nesting. The higher the percentage of utilization, the more economical the process. Enjoy the benefits of significantly increased cost savings.
Anti-burning mineral casting - Bodor's newly developed anti-burning casting material provides numerous advantages in slag removal, operations, and modular design. When in use, material residue automatically separates from the anti-burning plate, largely lowering maintenance costs and offering better durability. Its lightweight structure as well makes it easy to replace.
Nesting software - Auto nest up to 50 individual parts, ensuring maximum efficiency and less waste.

Includes

Bodor’s Genius: cutting head with programmable motorised lens and Collision Protection
Bodor Power: is the backbone of any laser cutting system, and BodorPower takes it to the next level. This original laser source is the key to Bodor’s high power processing (up to 60kW). It ensures longer lifespans, safer operations, and superior cutting results of every Bodor cutting machine.
BodorThinker: serves as the intelligent core of Bodor’s laser cutting solutions. This control system integrates seamlessly with MES and ERP systems, facilitating automated production process management and information exchange through standardised communication protocols.
Door-open Protection
Cutting view camera
21" LCD Touch screen
Local Service and Support
Oxygen & Nitrogen Regulators with hoses
*12 month warranty on machine parts & labor
Commissioning & Testing Included (Metro Areas)
Comprehensive Operator Training Included (Metro Areas)
*Five year factory warranty on - Bodor Thinker Control System, Bodor Power Laser Source, Bodor Genius Laser Head.

Optional Accessories

MMF-4L - Laser Fume Extraction 5.5kW (W2723)

Specifications

Compare Product Range

Specifications

ORDER CODE	L78102
(Type)MODEL	i6 3kW
(kW)Laser Power	3
(mm)Cutting Table Capacity	2000 x 1000
(G)Max acceleration	1.5
(mm)Positioning accuracy	±0.05
(mm)Repeatability	±0.03
(m/min)Compound Rapid speed	91
Laser Type	Fiber Laser
Laser Source	BodorPower
Laser Head	BodorGenius
Control System	BodorThinker
Door-open Protection	Yes
(kg)Max. Table Load Capacity	400
Active Obstacle Avoidance	Yes
One-Click Processing	No
Intelligent Remnant Layout	Yes
Lightning Piercing	Yes
High Speed Cutting Expert Database	Yes
Auto Focus Laser Head	Yes
Automatic Nozzle Change	No
Anti-Burning Mineral Casting Plate	Yes
Nesting Software	Yes -Compatible with Tekla
(Type)Drawing File	G Code, DXF, DWG
Laser Scanning Cutting	Optional
Transfer Table - Motorised	Optional for i6 &i7 only
Bevel Cutting	No
(kg)Nett Weight	3110
(mm)Machine Size	4049×1955×2230
