Refrigerated Air Dryer - AMD-12

PERFORMANCE:
AMD dryer have excellent performance even in instances of high ambient temperatures up to 45ºC and high inlet temperatures of 55ºC, ensuring a reduced compressed air pressure drop.

FUNCTIONALITY:
operation of the AMD dryer is monitored by the DMC15 electronic controller which indicates the dew-point temperature digitally, it also controls the condensation drain valve via a timer and the condenser fan via a probe. A hot gas bypass valve allows the dryer to operate at part load and prevents the evaporator from freezing. The ALU-DRY aluminium module has a vertical flow layout ensuring the wet compressed air flows down to the automatic drain.

ECONOMY:
AMD dryer are sized to match standard air compressor outputs and therefore it is unnecessary to select a larger model. Air compressor dryer combinations have been tested and certified within operation limits shown in the technical feature brochure.
