L33HS OPTi-Turn - Optimum CNC Lathe
330 x 630mm Turning Capacity
L770
1 of 18
Right View With Swivel Controller
2 of 18
Left View
3 of 18
Control Panel
4 of 18
Siemens Control
5 of 18
6 Station Tool Changer
6 of 18
3 Jaw Chuck
7 of 18
Sliding Front Door
8 of 18
Safety Interlock For Front Sliding Door
9 of 18
Machine Status Light
10 of 18
Front View of Chuck and Tool Changer
11 of 18
LED Light
12 of 18
Tailstock
13 of 18
Side Access Door
14 of 18
Side View Inside
15 of 18
Spindle Drive System
16 of 18
Pull Out Swarf Drawer
17 of 18
Pull Out Coolant Drawer
18 of 18
Order Code: L770
ex-gst
inc-gst
$
35,950.00
$
39,545.00
415V / (NO PLUG)
1 Year Warranty
1 Year Warranty
Description
L33HS OPTi-Turn - Optimum CNC Lathe
330 x 630mm Turning Capacity
Overview
Designed and Engineered in Germany the OPTIMUM CNC range is a market leader in Europe and is now available in Australia through Hare and Forbes Machinery House. Offering exceptional value for money the OPTIMUM range can have you set up for in house CNC machining at a fraction of the financial outlay previously required.
Features
- Siemens 808D CNC control
- 6 station auto turret with 16mm Tooling
- 4000rpm main spindle speed
- 150mm 3 jaw chuck A2 mount.
- 42mm Spindle bore
- 330mm Swing over bed
- Tailstock with MT3
- 2-Axis servo motor control
- Constant surface speed control
- Flood coolant system
- Full CE Safety enclosure with Safety PLC
- Central lubrication unit
Optional Accessories
- Delivery & Installation
- Training packages in Hare & Forbes Tech Centre
- Tooling
Compare Product Range
Specifications
| ORDER CODE | L770 |
|---|---|
| MODEL | L33HS OPTi-Turn |
| (mm)Tool Height | 16 |
| (mm)Maximum Turning Length | 600 |
| (mm)Maximum Turning Diameter | 275 |
| (mm)Distance Between Centres | 630 |
| (mm)Swing Over Bed | 330 |
| (mm)Centre Height | 165 |
| (mm)Bed Width | 206 |
| (mm)Spindle Bore | 42 |
| (Type)Spindle Taper | A2-4 |
| (mm)Turning Over Cross Slide | 140 |
| (MT)TailStock Taper | 3 |
| (mm)Tailstock Travel | 100 |
| (rpm)Spindle Speed Range | 40 - 4000 |
| (No.)Tool Position Number | 6 |
| (kW / hp)Motor Power | 3.7 / 5 |
| (V / amp)Voltage / Amperage | 415 |
| (kg)Nett Weight | 1250 |
- Compare:
- Wishlist:
- ORDER CODE
- MODEL
- (mm)Tool Height
- (mm)Accuracy
- (mm)Repeatability
- (mm)Maximum Turning Length
- (mm)Maximum Turning Diameter
- (mm)Distance Between Centres
- (mm)Swing Over Bed
- (mm)Centre Height
- (mm)Bed Width
- (mm)Spindle Bore
- (Type)Spindle Taper
- (mm)Turning Over Cross Slide
- (MT)TailStock Taper
- (mm)Tailstock Travel
- (rpm)Spindle Speed Range
- (No.)Tool Position Number
- (kW / hp)Motor Power
- (V / amp)Voltage / Amperage
- (kg)Nett Weight
- (ex-gst)Pricing
- (inc-gst)
-
Compare
-
Wishlist
- L770
- L33HS OPTi-Turn
- 16
- ~
- ~
- 600
- 275
- 630
- 330
- 165
- 206
- 42
- A2-4
- 140
- 3
- 100
- 40 - 4000
- 6
- 3.7 / 5
- 415
- 1250
- $35,950.00
- $39,545.00
- ADD TO CART
- Package Deal
-
Compare
-
Wishlist
- L770A
- L33HS OPTi-Turn PACKAGE
- 16
- ~
- ~
- 600
- 275
- 630
- 330
- 165
- 206
- 42
- A2-4
- 140
- 3
- 100
- 40 - 4000
- 6
- 3.7 / 5
- 415
- 1250
- $36,450.00
- $40,095.00
- ADD TO CART
- Back In Stock Soon
-
Compare
-
Wishlist
- L771
- L40 OPTi-Turn
- 20
- ~
- ~
- 900
- 400
- 1000
- 400
- 200
- 320
- 60
- A2-6
- 240
- 4
- 120
- 25 - 2500
- 8
- 7.5 / 10
- 415
- 2400
- $46,990.00
- $51,689.00
- ADD TO CART
