Order Code: V304
ex-gst
inc-gst
$ 280.00
$ 308.00
1 Year Warranty
Made in Taiwan
Description

VA-4 - Anglock Machine Vice

100mm
Overview
The VERTEX Anglock vice has a ductile steel body with hardened and ground movable steel jaw.
Features
  • All surfaces are precision ground and the bed is flame hardened
  • Spherical segment allows for all directional alignment
  • When clamping, a downward pressure of 1kg is exerted by the movable jaw for every 2kg of clamping pressure, preventing the work piece from tilting
  • Bearing thrust collar cuts friction and increases clamping pressure
  • Swivel base is graduated to 360ยบ
Compare Product Range Compare Selected
  • Compare:
  • Wishlist:
  • ORDER CODE
  • MODEL
  • (mm)Size
  • (mm)A
  • (mm)B
  • (mm)C
  • (mm)D
  • (mm)E
  • (mm)F
  • (mm)G
  • (mm)H
  • (kg)Nett Weight
  • (ex-gst)Pricing
  • (inc-gst)
  • V304
  • Compare
  • Wishlist
  • V304
  • VA-4
  • 100
  • 102
  • 325
  • 165
  • 96
  • 36
  • 103
  • 243
  • 32
  • 20
  • $280.00
  • $308.00
  • ADD TO CART
  • V305
  • Compare
  • Wishlist
  • V305
  • VA-5
  • 127
  • 127
  • 369
  • 193
  • 128
  • 33
  • 110
  • 254
  • 32
  • 31
  • $320.00
  • $352.00
  • ADD TO CART
  • V306
  • Compare
  • Wishlist
  • V306
  • VA-6
  • 152
  • 152
  • 425
  • 209
  • 149
  • 46
  • 142
  • 300
  • 38
  • 45
  • $330.00
  • $363.00
  • ADD TO CART
  • V3061
  • Compare
  • Wishlist
  • V3061
  • TM-160
  • 160
  • 160
  • 415
  • 210
  • 150
  • 45
  • 170
  • 295
  • 37
  • 45
  • $241.00
  • $265.10
  • ADD TO CART
  • V307
  • Compare
  • Wishlist
  • V307
  • VA-8
  • 203
  • 203
  • 552
  • 295
  • 178
  • 50
  • 197
  • 368
  • 44
  • 97
  • $750.00
  • $825.00
  • ADD TO CART
