Electric Motors E050

CWTC3703C - Electric Motor

1HP
1410rpm
E050 1 of 1
CMG
Discontinued
Order Code: E050
240V / 10A
1 Year Warranty
Sorry, this Product is no longer available
Click Here To View All Electric Motors
Compare
Wishlist
Print
Description
Description

CWTC3703C - Electric Motor

1HP
1410rpm
Overview
The popular CMG General Purpose series motor is a strong performer, ideally suited for most general applications. The series is designed to suit domestic, commercial and industrial applications. With no wiring necessary, it is simple and convenient to use.
Features
  • High starting torque CSCR winding design
  • TEFC cooling
  • IP44 protection against dust and water ingress
  • Heavy Duty rolled steel case with B56 base
  • Manual reset thermal overload protection
  • 240V single phase with 2 metre flex & plug standard
  • Reversible motor
  • Foot mounted
Specifications
Downloads
You may also like
A1200
305mm (12") Hook & Loop Backing Disc
Self Adhesive Back
HAFCO
Code: A1200

$ 27.00 ex
$ 29.70 inc

Add to Cart
G160
ATBG600/8 - Industrial Bench Grinder
Ø200mm Fine & Coarse Wheels (240V)
0.6kW - 0.8HP Motor Power
ABBOTT & ASHBY
Code: G160

$ 300.00 ex
$ 330.00 inc

Add to Cart
D422
Drill Sleeve - Morse Taper
3MT x 2MT
TOOLMASTER
Code: D422

$ 18.00 ex
$ 19.80 inc

Add to Cart
Compare Product Range Compare Selected
  • Compare:
  • Wishlist:
  • ORDER CODE
  • MODEL
  • (kW / hp)Motor Power
  • (rpm)Speed
  • (mm)Shaft Diameter
  • (Yes / No)Reversible Motor
  • (Yes / No)Fan Cooled
  • (V)Voltage
  • Amps Required
  • Input Power Supply Connection
  • (ex-gst)Pricing
  • (inc-gst)
  • E040
  • Compare
  • Wishlist
  • E040
  • EM1-14
  • 0.75 / 1
  • 1440
  • Ø15.87 (5/8")
  • Yes
  • Yes
  • 240
  • 10
  • Includes Plug & Lead
  • $220.00
  • $242.00
  • ADD TO CART
  • E092
  • Compare
  • Wishlist
  • E092
  • EM2-14
  • 1.5 / 2
  • 1440
  • Ø19
  • Yes
  • Yes
  • 240
  • 10
  • Includes Plug & Lead
  • $340.00
  • $374.00
  • ADD TO CART
  • E084
  • Compare
  • Wishlist
  • E084
  • EM25-28
  • 1.875 / 2.5
  • 2800
  • Ø19
  • Yes
  • Yes
  • 240
  • 15
  • Includes Plug & Lead
  • $300.00
  • $330.00
  • ADD TO CART
  • E112
  • Compare
  • Wishlist
  • E112
  • EM3-28
  • 2.25 / 3
  • 2800
  • Ø19
  • Yes
  • Yes
  • 240
  • 15
  • Includes Plug & Lead
  • $320.00
  • $352.00
  • ADD TO CART
  • Order In LK083
  • Compare
  • Wishlist
  • LK083
  • ~
  • 2
  • 1400
  • 24
  • ~
  • Yes
  • 240
  • 10
  • ~
  • N/A
  • N/A
  • ENQUIRE
  • Discontinued 2MD1106
  • Compare
  • Wishlist
  • 2MD1106
  • ~
  • 1.5
  • 1400
  • 19
  • ~
  • Yes
  • 240
  • 6.8
  • ~
  • N/A
  • N/A
  • ENQUIRE
  • Discontinued MQ460
  • Compare
  • Wishlist
  • MQ460
  •
  •
  •
  •
  •
  •
  •
  • ~
  •
  • N/A
  • N/A
  • ENQUIRE
  • Discontinued 1HB002
  • Compare
  • Wishlist
  • 1HB002
  •
  •
  •
  •
  •
  •
  •
  • ~
  •
  • N/A
  • N/A
  • ENQUIRE
  • Discontinued E050
  • Compare
  • Wishlist
  • E050
  • CWTC3703C
  • 0.75 / 1
  • 1410
  • Ø5/8"
  • Yes
  • Fan Cooled
  • 240 / 10
  • ~
  • 10
  • N/A
  • N/A
  • ENQUIRE
