SWIFTCUT
SKU: P9010
ex-gst
inc-gst
$ 29,450.00
$ 32,395.00
240V / 30A
1 Year Warranty
Made in United Kingdom
Finance from $85 / week
Description

SwiftCut 1250W - CNC Plasma Cutting Table

Water Tray System, Hypertherm Powermax 45XP
Cuts up to 12mm
Overview
Swiftcut 1250WT - CNC Plasma 1250 x 1250mm Cutting Table and Hypertherm Powermax 45XP to cut up to 12mm

Our Swiftcut plasma cutting tables offer an affordable alternative to outsourcing, enabling you to take greater control of your business.
Features
  • Water tray for efficient control of sparks and fumes
  • Removable stainless steel splash guards for side rail protection
  • Dropped rails for ease of loading full sheets
  • Gantry parking to allow full sheet to be loaded overhead
  • Heavy duty steel construction with durable paint finish
  • Smooth motion linear V wheels
  • Dual drive Y-axis
  • Proximity sensing for reliable and robust switching
  • Auto adjusting X-axis linear V rollers
  • Rack and pinion drive system
  • Magnetic breakaway head eliminates damage to torch and improves safety
  • Cut metal up to 25mm thick depending on the Hypertherm Powermax unit selected
  • Digital Torch-Height Control (DTHC) Quick response for improved cut quantity and improved torch consumable life
  • Dynamic Cut Control (DCC) on Hypertherm powermax 45XP/65/85/105/125, Software control of cutting amps and air pressure, Error messages from plasma unit displayed on Swiftcut control screen, Varied cutting speed control from the console for improved cut quality. INDUSTRY 1st UNIQUE TO SWIFT-CUT

  • OPERATORS PANEL:
  • Free-Standing Operators Console
  • 18.5" flat panel LCD monitor
  • Built in controller with dual CPU
  • Wireless keyboard and mouse
  • E-Stop safety button
  • External USB and network port for transfer of files and network connection
  • Easy access for maintenance

  • SOFTWARE:
  • Swift-Cam level 1 CAD/CAM program. Conversion of any DXF file to Swiftcut machine code, manual nesting of parts, 2D parametric library, sheet properties and 2D cycle simulation
  • Swiftcut CNC control software
  • Team viewer software
Optional Accessories
  • MACHINE UPGRADES:
  • Swift-Trace Camera - Optical reverse engineering, convert a hand drawn sketch to a DXF file for quick production.
  • Go from line drawings to cutting your design in four simple steps with the Swift-Trace system.

  • Swift-Marker Unit - Integrated pneumatic marker. Can be used to automatically mark text, fold lines and centre marks on components prior to profiling to avoid costly second operations.
  • Great for part numbering or serial numbering of parts.

  • SOFTWARE UPGRADES:
  • Swift-Cam level 2 (P9051) Level 1 + auto nesting with 1 click plate utilisation
  • Swift-Cam level 3 (P9052) Level 2 + cutting path auto correction, 3D simulation and cycle time calculation
  • HVAC (P9053) Parametric shape library of adjustable drawings for converting 3D components into 2D cutting profiles commonly used in the HVAC market. Can be used alongside Swift-CAM Level 1 or Level 2 for auto nesting parts.
Recommended Accessories
Compare Product Range Compare Selected
  • Compare:
  • Wishlist:
  • ORDER CODE
  • MODEL
  • (mm)Cutting Table Capacity
  • (mm)Thickness Cutting Capacity - Mild Steel
  • Plasma Cutting Unit
  • (amp)Current Output
  • Duty Cycle (Typical)

  • (Type)Fume Management

  • (Type)Cutting Gas
  • (V)Plasma Unit Input Voltage
  • (amp)Plasma Unit Input Amperage
  • (ex-gst)Pricing
  • (inc-gst)
  • P9000
  • Compare
  • Wishlist
  • P9000
  • SWIFTY
  • 610 x 610
  • 8
  • Unimig Razor Cut 45
  • 20 - 45
  • 25% @ 45A
    100% @ 22.5A
  • Water Tray System

  • Compressed Air
  • 240V
  • 15
  • $8,520.00
  • $9,372.00
  • ADD TO CART
  • P9001
  • Compare
  • Wishlist
  • P9001
  • SWIFTY XP
  • 610 x 610
  • 10
  • Hypertherm 45XP
  • 20 - 45
  • 50% @ 45A
    100% @ 32A
  • Water Tray System

  • Compressed Air
  • 240V 30A no plug supplied
  • 30
  • $11,120.00
  • $12,232.00
  • ADD TO CART
  • P9010
  • Compare
  • Wishlist
  • P9010
  • Swift-Cut 1250W
  • 1250 x 1250
  • 12
  • Hyperth. Powermax 45XP
  • 10 - 45
  • 50% @ 45A
    100% @ 32A
  • Water Tray System

  • Air or Nitrogen
  • 240V - 415V with Neutral
  • 30
  • $29,450.00
  • $32,395.00
  • ADD TO CART
  • P9011
  • Compare
  • Wishlist
  • P9011
  • Swift-Cut 1250W
  • 1250 x 1250
  • 16
  • Hypertherm Powermax 65
  • 20 - 65
  • 50% @ 65A
    100% @ 46A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 15
  • $30,950.00
  • $34,045.00
  • ADD TO CART
  • P9012
  • Compare
  • Wishlist
  • P9012
  • Swift-Cut 1250W
  • 1250 x 1250
  • 20
  • Hypertherm Powermax 85
  • 25 - 85
  • 60% @ 85A
    100% @ 66A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 20
  • $32,950.00
  • $36,245.00
  • ADD TO CART
  • P9013
  • Compare
  • Wishlist
  • P9013
  • Swift-Cut 1250W
  • 1250 x 1250
  • 22
  • Hypertherm Powermax 105
  • 30 - 105
  • 80% @ 105A
    100% @ 94A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 28
  • $34,500.00
  • $37,950.00
  • ADD TO CART
  • P9014
  • Compare
  • Wishlist
  • P9014
  • Swift-Cut 1250W
  • 1250 x 1250
  • 25
  • Hypertherm Powermax 125
  • 30 - 125
  • 100% @ 125A

  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 36
  • $37,950.00
  • $41,745.00
  • ADD TO CART
  • P9020
  • Compare
  • Wishlist
  • P9020
  • Swift-Cut 2500W
  • 2500 x 1250
  • 12
  • Hyperth. Powermax 45XP
  • 10 - 45
  • 50% @ 45A
    100% @ 32A
  • Water Tray System

  • Air or Nitrogen
  • 240V - 415V with Neutral
  • 30
  • $33,250.00
  • $36,575.00
  • ADD TO CART
  • P9021
  • Compare
  • Wishlist
  • P9021
  • Swift-Cut 2500W
  • 2500 x 1250
  • 16
  • Hypertherm Powermax 65
  • 20 - 65
  • 50% @ 65A
    100% @ 46A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 15
  • $34,850.00
  • $38,335.00
  • ADD TO CART
  • P9022
  • Compare
  • Wishlist
  • P9022
  • Swift-Cut 2500W
  • 2500 x 1250
  • 20
  • Hypertherm Powermax 85
  • 25 - 85
  • 60% @ 85A
    100% @ 66A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 20
  • $36,850.00
  • $40,535.00
  • ADD TO CART
  • P9023
  • Compare
  • Wishlist
  • P9023
  • Swift-Cut 2500W
  • 2500 x 1250
  • 22
  • Hypertherm Powermax 105
  • 30 - 105
  • 80% @ 105A
    100% @ 94A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 28
  • $38,450.00
  • $42,295.00
  • ADD TO CART
  • P9024
  • Compare
  • Wishlist
  • P9024
  • Swift-Cut 2500W
  • 2500 x 1250
  • 25
  • Hypertherm Powermax 125
  • 30 - 125
  • 100% @ 125A

  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 36
  • $41,900.00
  • $46,090.00
  • ADD TO CART
  • P9030
  • Compare
  • Wishlist
  • P9030
  • Swift-Cut 3000W
  • 3000 x 1500
  • 12
  • Hyperth. Powermax 45XP
  • 10 - 45
  • 50% @ 45A
    100% @ 32A
  • Water Tray System

  • Air or Nitrogen
  • 240V - 415V with Neutral
  • 30
  • $36,900.00
  • $40,590.00
  • ADD TO CART
  • P9035
  • Compare
  • Wishlist
  • P9035
  • Swift-Cut 3000DD
  • 3000 x 1500
  • 12
  • Hyperth. Powermax 45XP
  • 10 - 45
  • 50% @ 45A
    100% @ 32A
  • Downdraft System

  • Air or Nitrogen
  • 240V - 415V with Neutral
  • 30
  • $38,600.00
  • $42,460.00
  • ADD TO CART
  • P9031
  • Compare
  • Wishlist
  • P9031
  • Swift-Cut 3000W
  • 3000 x 1500
  • 16
  • Hypertherm Powermax 65
  • 20 - 65
  • 50% @ 65A
    100% @ 46A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 15
  • $38,500.00
  • $42,350.00
  • ADD TO CART
  • P9036
  • Compare
  • Wishlist
  • P9036
  • Swift-Cut 3000DD
  • 3000 x 1500
  • 16
  • Hypertherm Powermax 65
  • 20 - 65
  • 50% @ 65A
    100% @ 46A
  • Downdraft System

  • Air or Nitrogen
  • 415V with Neutral
  • 15
  • $40,200.00
  • $44,220.00
  • ADD TO CART
  • P9032
  • Compare
  • Wishlist
  • P9032
  • Swift-Cut 3000W
  • 3000 x 1500
  • 20
  • Hypertherm Powermax 85
  • 25 - 85
  • 60% @ 85A
    100% @ 66A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 20
  • $40,500.00
  • $44,550.00
  • ADD TO CART
  • P9037
  • Compare
  • Wishlist
  • P9037
  • Swift-Cut 3000DD
  • 3000 x 1500
  • 20
  • Hypertherm Powermax 85
  • 25 - 85
  • 60% @ 85A
    100% @ 66A
  • Downdraft System

  • Air or Nitrogen
  • 415V with Neutral
  • 20
  • $42,200.00
  • $46,420.00
  • ADD TO CART
  • P9033
  • Compare
  • Wishlist
  • P9033
  • Swift-Cut 3000W
  • 3000 x 1500
  • 22
  • Hypertherm Powermax 105
  • 30 - 105
  • 80% @ 105A
    100% @ 94A
  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 28
  • $41,950.00
  • $46,145.00
  • ADD TO CART
  • P9038
  • Compare
  • Wishlist
  • P9038
  • Swift-Cut 3000DD
  • 3000 x 1500
  • 22
  • Hypertherm Powermax 105
  • 30 - 105
  • 80% @ 105A
    100% @ 94A
  • Downdraft System

  • Air or Nitrogen
  • 415V with Neutral
  • 28
  • $43,800.00
  • $48,180.00
  • ADD TO CART
  • P9034
  • Compare
  • Wishlist
  • P9034
  • Swift-Cut 3000W
  • 3000 x 1500
  • 25
  • Hypertherm Powermax 125
  • 30 - 125
  • 100% @ 125A

  • Water Tray System

  • Air or Nitrogen
  • 415V with Neutral
  • 36
  • $45,400.00
  • $49,940.00
  • ADD TO CART
  • P9039
  • Compare
  • Wishlist
  • P9039
  • Swift-Cut 3000DD
  • 3000 x 1500
  • 25
  • Hypertherm Powermax 125
  • 30 - 125
  • 100% @ 125A

  • Downdraft System

  • Air or Nitrogen
  • 415V with Neutral
  • 36
  • $47,250.00
  • $51,975.00
  • ADD TO CART
  • P9040
  • Compare
  • Wishlist
  • P9040
  • Swift-Cut 3000XP
  • 3000 x 1500
  • 32
  • Hypertherm MAXPRO 200
  • 32 - 200
  • 100% @ 200A

  • Water Table or
    Down Draft system
  • Air, O2, N2
  • 415V with Neutral
  • ~
  • $89,500.00
  • $98,450.00
  • ADD TO CART
  • P980
  • Compare
  • Wishlist
  • P980
  • BPS-1503
  • 1700 x 3200
  • ~
  • ~
  • ~
  • ~

  • ~

  • ~
  • ~
  • ~
  • Please Call
  • Please Call
  • ADD TO CART
  • P982
  • Compare
  • Wishlist
  • P982
  • BPL-H
  • Refer Table Below
  • ~
  • ~
  • ~
  • ~

  • ~

  • ~
  • ~
  • ~
  • Please Call
  • Please Call
  • ADD TO CART
  • P984
  • Compare
  • Wishlist
  • P984
  • BPH
  • Refer Table Below
  • ~
  • ~
  • ~
  • ~

  • ~

  • ~
  • ~
  • ~
  • Please Call
  • Please Call
  • ADD TO CART
