FB90120-M - CertiFlat fabBLOCK 3D Welding Table Top
Tab & Slot U-Weld
900 x 1200 x 150mm Table Top (LxWxH)
CertiFlat’s new fabBLOCK’s are the ultimate welding table system made in the USA. Designed using proprietary Tab & Slot methodology for building stiff and accurate welding fixtures that has been proven in real world manufacturing setups for over 15 years.
fabBLOCK Tables are built from tough 6.35mm Hot Rolled Pickled & Oiled Steel using state of the art CNC Laser Cutting technology for an exceptional fit-up. fabBLOCK’s assemble easily, by following the proper sequence (shown in easy to understand step by step instructions & video) the internal webbing forces the table flat during assembly and keeps it that way for years of trouble free and accurate welding.
Completely modular across all fabBLOCK sizes, allows you to easily add additional fabBLOCK’s or fabWing’s for unlimited configurations. All fabBLOCK’s incorporate the industry standard Ø16mm hole on a 50 x 50mm grid pattern for easy access to clamps and tooling, Great for use with Strong Hand Tools FixturePoint clamping systems.
- Engineered Tab & Slot stiffening ribs for a guaranteed flat surface.
- Proprietary Heat-Zone™ design to eliminate warping during assembly and welding
- Modular design allowing easy joining of additional fabBLOCK’s for unlimited configurations
- Working surfaces on all five sides for unlimited 3D fixturing configurations
- All parts are laser cut to a very tight tolerance maintaining very high precision.
- Ø16mm holes with a 50 x 50mm grid pattern
- Compatible with Strong Hand Tools FixturePoint clamp systems
- Please Note: assembly & welding is required to complete setup
- Leg kit
- FabWing’s to expand your fabBLOCK size or create an additional 3D surface for clamping
- Strong Hand Tools FixturePoint clamp systems
