DOOSAN MACHINE TOOLS
Order Code: L7224
ex-gst
inc-gst
$ 190,500.00
$ 209,550.00
1 Year Warranty
Made in South Korea
Finance from $85 / week
Description

PUMA 2600Y - Y Axis CNC Turning Centre

Overview
Basic Specifications
• 780mm Swing Over Bed
• 630mm Swing Over Saddle
• 760mm Turning Length
• 376mm Turning Ø
• 105mm (±52.5mm) Y Axis Travel
• 3600 (0.0010 Resolution) C Axis
• 220kg Main Spindle Capacity, 710kg Shaft Work Capacity

Main Spindle
• 81mm Bar Capacity
• 255mm Ø Hydraulic Chuck
• 3500RPM Spindle Speed
• 22kW Spindle Power
• 240Nm Spindle Torque

Tailstock
• MT5
• 100mm Quill Ø
• 100mm Quill Travel
• Programmable Positioning

Turret
• BMT 65 Tool Mounting
• 5000RPM Live Tool Speed
• 5.5kW Live Tool Power
• 47.1Nm Live Tool Torque
• 12 Station Turret
• 25mm Square / 50mm Ø Tool Capacity
• ER32 Live Tool Collet Size
• Eppinger Preci-Flex Tooling System


CNC Control
• Doosan Fanuc I Series (0i-MD) CNC Controller
• 10.4” Colour LCD Monitor
• Rigid-synchronised tapping
• Custom Macro B
• Ethernet Interface
• RS232 Interface
• USB & PCMCIA Memory Card Slot
• Doosan Ezi Guide “I” Conversational software:
• Graphical Turning Cycles
• Graphical Milling Cycles
• Full 3D Graphical Simulation
• Onboard G & M code assistance
• + more

Standard Equipment - Included
• 3 Jaw Hydraulic Power Chuck
• Chuck Cleaning Air Blast
• Eppinger rotary tool holders with Preci-Flex adapter set
• Coolant supply equipment
• Foot switches
• Transformer
• Full enclosure chip and coolant shield with front door interlock
• Hand tool kit
• Automatic lubrication equipment
• Comprehensive manuals incorporating, Operation, Maintenance, Programming, Spare Parts Diagrams, Hydraulic Schematics, Electrical Schematics and Ladder Diagrams.
• Safety name plates / tags where required
• Risk assessment
• Work light


Optional Equipment Included
• Chuck open close confirmation proximity switches
• Chip Conveyor (Side Discharge, Hinged Belt)
• Auto Tool Setter (Hydraulically operated)
• Coolant Oil Skimmer
• 7 Bar High Pressure Coolant
• Barfeed Interface
• Programmable Tailstock
• Chuck Cleaning Air Blast

Standard Turret Tool Holder Package Included
• 4 x OD Tool Holder (R & L)
• 3 x ID Tool Holder
• 1 x Face Tool Holder (R & L)
• 1 x U Drill Cap
• 2 x Straight Milling Unit
• 2 x Angular Milling Unit
• 1 x Boring Sleeve Kit
• 1 x U Drill Sleeve Kit
• 1 x Preci-Flex Adapter Kit
• 1 x ER 32 Milling Collet Set
• 1 x Hard & Soft Jaws

Local Service and Support
• Commissioning & Testing Included
• Comprehensive Operator Training Included
• Hare and Forbes In House Service And Applications Staff
• Ongoing Support For Life Of The Machine
Compare Product Range Compare Selected
  • Compare:
  • Wishlist:
  • ORDER CODE
  • MODEL
  • (mm)Swing
  • (mm)Max Turning Diameter
  • (mm)Turning Length
  • (mm)Chuck Diameter
  • (mm)Bar Diameter Capacity
  • (No.)Tool Stations
  • (rpm)Spindle Speed
  • (kW)Spindle Motor
  • Guideways
  • Control
  • Programming
  • (deg)C Axes Resolution
  • (rpm)Milling Speed
  • Milling Collets
  • (mm)Sub Chuck Diameter
  • (mm)Y Axis Travel
  • (ex-gst)Pricing
  • (inc-gst)
  • I8001
  • Compare
  • Wishlist
  • I8001
  • PUMA 2100/2600/3100
  • 680~850
  • 376-525
  • 520-3125
  • 210/380
  • 65~102
  • 10/12/24
  • 2800~4500
  • 18-30
  • Box Guide Way
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • Optional
  • Optional
  • Optional
  • Optional
  • Optional
  • Please Call
  • Please Call
  • ADD TO CART
  • L7224
  • Compare
  • Wishlist
  • L7222
  • PUMA 2600Y
  • 780
  • 376
  • 725
  • 255
  • 81
  • 12
  • 3500
  • 22
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER32
  • ~
  • 105 (±52.5)
  • $190,500.00
  • $209,550.00
  • ADD TO CART
  • L7223
  • Compare
  • Wishlist
  • L7223
  • PUMA 2600YB
  • 780
  • 376
  • 725
  • 300
  • 102
  • 12
  • 2800
  • 22
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER32
  • ~
  • 105 (±52.5)
  • $199,900.00
  • $219,890.00
  • ADD TO CART
  • L7225
  • Compare
  • Wishlist
  • L7225
  • PUMA 2600SY
  • 780
  • 376
  • 725
  • 250
  • 81
  • 12/24
  • 3500
  • 22
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER32
  • 150
  • 105 (±52.5)
  • $234,900.00
  • $258,390.00
  • ADD TO CART
  • L7242
  • Compare
  • Wishlist
  • L7242
  • PUMA 3100LY
  • 850 (720)
  • 420
  • 1285
  • 380
  • 102
  • 12
  • 2800
  • 22
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER32
  • ~
  • 130 (±65)
  • $239,600.00
  • $263,560.00
  • ADD TO CART
