DOOSAN MACHINE TOOLS
Order Code: L7120
ex-gst
inc-gst
$ 180,970.00
$ 199,067.00
1 Year Warranty
Made in South Korea
Finance from $85 / week
Description

PUMA GT3100M C Axis - CNC Turning Centre

Overview
Basic Specifications
• 720mm Swing Over Bed
• 590mm Swing Over Saddle
• 725mm Turning Length
• 376mm Turning Ø
• 3600 (0.0010 Resolution) C Axis
• 390kg Main Spindle Capacity, 1000kg Shaft Work Capacity

Main Spindle
• 102mm Bar Capacity
• 300mm Ø Hydraulic Chuck
• 2800RPM Spindle Speed
• 22kW Spindle Power
• 1123Nm Spindle Torque

Tailstock
• MT5
• 100mm Quill Ø
• 100mm Quill Travel
• Programmable Positioning

Turret
• BMT 65 Tool Mounting
• 5000RPM Live Tool Speed
• 7.5kW Live Tool Power
• 95.5Nm Live Tool Torque
• 12 Station Turret
• 25mm Square / 50mm Ø Tool Capacity
• ER32 Live Tool Collet Size
• Eppinger Preci-Flex Tooling System


CNC Control
• Doosan Fanuc I Series (0i-MD) CNC Controller
• 10.4” Colour LCD Monitor
• Rigid-synchronised tapping
• Custom Macro B
• Ethernet Interface
• RS232 Interface
• USB & PCMCIA Memory Card Slot
• Doosan Ezi Guide “I” Conversational software:
• Graphical Turning Cycles
• Graphical Milling Cycles
• Full 3D Graphical Simulation
• Onboard G & M code assistance
• + more

Standard Equipment - Included
• 3 Jaw Hydraulic Power Chuck
• Chuck Cleaning Air Blast
• Eppinger rotary tool holders with Preci-Flex adapter set
• Coolant supply equipment
• Foot switches
• Transformer
• Full enclosure chip and coolant shield with front door interlock
• Hand tool kit
• Automatic lubrication equipment
• Comprehensive manuals incorporating, Operation, Maintenance, Programming, Spare Parts Diagrams, Hydraulic Schematics, Electrical Schematics and Ladder Diagrams.
• Safety name plates / tags where required
• Risk assessment
• Work light


Optional Equipment Included
• Chuck open close confirmation proximity switches
• Chip Conveyor (Side Discharge, Hinged Belt)
• Auto Tool Setter (Hydraulically operated)
• Coolant Oil Skimmer
• 7 Bar High Pressure Coolant
• Barfeed Interface
• Programmable Tailstock

Standard Turret Tool Holder Package Included
• 4 x OD Tool Holder (R & L)
• 3 x ID Tool Holder
• 1 x Face Tool Holder (R & L)
• 1 x U Drill Cap
• 2 x Straight Milling Unit
• 2 x Angular Milling Unit
• 1 x Boring Sleeve Kit
• 1 x U Drill Sleeve Kit
• 1 x Preci-Flex Adapter Kit
• 1 x ER 25 Milling Collet Set
• 1 x Hard & Soft Jaws

Local Service and Support
• Commissioning & Testing Included
• Comprehensive Operator Training Included
• Hare and Forbes In House Service And Applications Staff
• Ongoing Support For Life Of The Machine
Compare Product Range Compare Selected
  • Compare:
  • Wishlist:
  • ORDER CODE
  • MODEL
  • (mm)Swing
  • (mm)Max Turning Diameter
  • (mm)Turning Length
  • (mm)Chuck Diameter
  • (mm)Bar Diameter Capacity
  • (No.)Tool Stations
  • (rpm)Spindle Speed
  • (kW)Spindle Motor
  • Guideways
  • Control
  • Programming
  • (deg)C Axis Resolution
  • (rpm)Milling Speed
  • Milling collets
  • Sub Chuck Diameter
  • Y Axis Travel
  • (ex-gst)Pricing
  • (inc-gst)
  • I8002
  • Compare
  • Wishlist
  • I8002
  • PUMA GT2100/2600/3100
  • 600-720
  • 300-460
  • 513-1275
  • 210-380
  • 65-102
  • 10/12/24
  • 2800-4500
  • 18.5-35
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • Optional
  • Optional
  • Optional
  • N/A
  • N/A
  • Please Call
  • Please Call
  • ADD TO CART
  • L7100
  • Compare
  • Wishlist
  • L7100
  • PUMA GT2100M
  • 600
  • 300
  • 513
  • 210
  • 65
  • 12
  • 4500
  • 18.5
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER25
  • ~
  • ~
  • $117,500.00
  • $129,250.00
  • ADD TO CART
  • L7110
  • Compare
  • Wishlist
  • L7110
  • PUMA GT2600M
  • 630
  • 410
  • 610
  • 250
  • 81
  • 12
  • 3500
  • 22
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER25
  • ~
  • ~
  • $134,400.00
  • $147,840.00
  • ADD TO CART
  • L7120
  • Compare
  • Wishlist
  • L7120
  • PUMA GT3100M
  • 720
  • 376
  • 725
  • 305
  • 102
  • 12
  • 2800
  • 22
  • Box Guideway
  • Doosan Fanuc I Series
  • EZI Guide I Conversational
  • 0.001
  • 5000
  • ER32
  • ~
  • ~
  • $180,970.00
  • $199,067.00
  • ADD TO CART
