THIS PRODUCT IS NO LONGER AVAILABLE. Click to see similar products > Drilling Machines TAFE
PD-35 Bench Drill
  • 1 of 18
  • 2 of 18
    Magnetic Switch and Safety Stop Switch
  • 3 of 18
    Lockable Switch
  • 4 of 18
    Safety Stop Switch
  • 5 of 18
    Safety Micro Switch on Belt Cover
  • 6 of 18
    Adjustable Safety Chuck Guard
  • 7 of 18
    Tilting and Rotating Cast Iron Table
  • 8 of 18
    Speed Chart
  • 9 of 18
    B Section Belt Drive System
  • 10 of 18
    Quill Handle
  • 11 of 18
    Drilling Depth Stop Setting with Scale
  • 12 of 18
    Motor and Belt Tension Lever and Lock
  • 13 of 18
    Base Cabinet
  • 14 of 18
    T Slot Base
  • 15 of 18
    1hp 415V Motor
  • 16 of 18
    Rear View
  • 17 of 18
    13mm Keyless Drill Chuck (C292)
  • 18 of 18
    3MT x JT6 Drill Chuck Arbor (D443)
Order Code: K8781
QLD Schools / TAFE - PD-35 Bench Drill (415V)
QLD Contract Item No.25
QLD Contract No.
QLD Item No.25
Schools / TAFE PD-35B
Bench / Pedestal Type
Duty Type
Drill Capacity (mm)
Spindle Taper (MT)
Spindle Travel (mm)
Throat Depth (mm)
Quill Diameter (mm)
Collar Diameter (mm)
Column Diameter (mm)
Spindle To Table (mm)
Spindle To Base (mm)
Table Shape
Micro Switch On Pulley Guard (Yes / No)
Table Size
350 x 350
Spindle Drive Type
B Section Belt
Spindle Steps (No.)
Spindle Speeds (RPM)
90 - 1680
Motor Power (kW / hp)
0.75 / 1
Voltage / Amperage (V / amp)
Overall Height (mm)
Nett Weight (kg)
We for many years have been working in close consultation with education departments to ensure the most suitable equipment is provided to our schools and TAFE, not only does it comply with the departments stringent safety requirements but is built to last the distance. That's why we consider our company to be a specialist when it comes to supplying quality Wood Work and Metal Working Machinery for Public or Private Schools, TAFE Colleges and Trade Training Centres in all states of Australia.
  • Ideal for industrial workshop use
  • Quiet "B" section V-belt drive system
  • Quick action belt tensioning lever
  • Adjustable safety drilling chuck guard with swivel screen
  • Safety micro switch on belt cover
  • Safety magnetic-type switch
  • Emergency stop switch
  • Rack & pinion table height adjustment with locking lever
  • Thick walled column ensuring greater rigidity
  • Table tilts left & right to 45º & rotates 360º
  • Drilling depth stop setting with scale
  • T slotted work table
  • 2 speed high /low switch
  • 18 Spindle speeds, 90-180, 150-300, 160-320, 215-430, 240-480, 310-620, 525-1050, 600-1200, 840-1680rpm
  • Fan-cooled 415 volt motor rated for continuous use with overload protection
  • Includes heavy duty cabinet stand
  • 13mm Keyless Drill Chuck (C292)
  • 3MT x JT6 Drill Chuck Arbor (D443)

Product Brochure
1.76 MB
Spare Parts Ordering
To assist you in ordering your spare part quicker than ever before, we have listed our most common spare parts to suit our Hafco Machinery for purchase online. Just choose between the 2 options outlined below, to find exactly what you are looking for. If you need further assistance please contact us.
Option 1
Browse through the "Common Spare Parts" tab below . Once you have identified your part, you can add it to your cart by clicking on the "+ ADD TO CART" button. If you wish to add multiples of this part you can either click the "+ ADD TO CART" button as many times as you like or click on the "VIEW CART" button and change the order quantity, prior to completing your order.
Option 2
If your part is NOT listed in the "Common Spare Parts" tab below , click the "MORE INFO" button to complete the "Spare Parts Enquiry Form".
This will provide you with the option to email your spare part enquiry direct to our Spare Parts and Service Department, or if you wish, you can download a printable version of this enquiry form which will include a copy of the Parts List to suit this machine (if available). Further instructions for the return email address or fax number of this printable form is provided on the document for your convenience.
NOTE: Please remember to clearly identify your part on the included parts diagram if necessary so that we can respond as quickly as possible with a price and availability for the part(s) you require.
