UNIMIGVIPER 150
Multi-Function Inverter Welder-MIG-MMA Package Deal
  • 1 of 4
    K019
  • 2 of 4
    VIPER 150
  • 3 of 4
    Front View (1)
  • 4 of 4
    With Included Accessories
Order Code: K019
VIPER 150 - Multi-Function Inverter Welder-MIG-MMA Package Deal (240V)
30-150 Amps
#KUMJRVM150
UNIMIG
On Special
ex GST
inc GST
$530.00
$583.00
$500.00
$550.00

Package Contains:
ex GST
inc GST
ORDER CODE
K019
MODEL
VIPER 150 Package
Type
MIG / MMA

Multifunction
Part Number
KUMJRVM150
Voltage (V)
240
Recommended Plug Amperage (amp)
10
Welding Current Range MIG (amp)
30 - 150
Welding Current Range MMA (amp)
10 - 130
Duty Cycle
15% @ 150amp
Wire Spool Size (kg)
5
Ferrous Wire Size - Range (mm)
0.6 - 0.8
Stainless Steel Wire Size - Range (mm)
0.6 - 0.8
Aluminium Wire Size - Range (mm)
0.6 - 0.8
Recommended Generator (KVA)
7
Dimensions (mm)
485 x 205 x 320
Nett Weight (kg)
12.5
Description
The VIPER MIG150 is a new inverter-based portable MIG welding machine with added MMA function. The MIG function allows you to weld with both Gas Shielded and Gas-less wire applications. Easy step-less adjustment of voltage and wire feed make for easy setting of welding parameters giving excellent welding results. Wire Inch gives easy feeding of the wire during set up without gas wastage and the Burn Back adjustment leaves the wire out ready for the next weld. MMA welding capability delivers easy electrode welding with high quality results, including cast Iron and stainless. Being 240v single phase gives great versatility.

Ideal for DIY and home workshop. Designed and built to our specification. Certified to - AS/NZ60974-1
Features
  • MIG with Gas and Gasless wire function
  • 5Kg Spools
  • Tolerant to variable power supply
  • Portable
  • Burnback adjustment
  • Wire Inch
  • Compliant to AS/NZ60947.1 Standard
Includes
  • VIPER MIG 150
  • SB15 3M Sure Grip MIG Torch
  • UNI-FLAME Twin Gauge Argon Regulator
  • 2M Gas Hose Complete with fittings
  • Flux Core Wire Roller 0.8-0.9mm
  • Arc Lead Set
  • Ø0.8mm x 4.5kg Gasless - Flux Core - MIG Welding Wire (W145B)


Product Brochure

180 Manual
1.86 MB
Select your Postcode & Suburb to estimate the delivery fee for this product.
Postcode & Suburb:
Freight is estimated from the nearest branch that has stock available.
Our delivery contractors operate Monday to Friday only, excluding public holidays.
All orders are processed in order of payment receipt.
Our aim is to despatch your goods as quickly as possible, however despatch times may take longer than our standard 3 to 5 day service during peak periods or according to stock levels, if this is the case we will advise you before processing your order.
More questions? Visit our delivery information page

  • VIPER 150 Package (K019)
ORDER CODE
MODEL
Type

Part Number
Voltage (V)
Recommended Plug Amperage (amp)
Welding Current Range MIG (amp)
Welding Current Range MMA (amp)
Welding Current Range TIG (amp)
Duty Cycle
Wire Spool Size (kg)
Ferrous Wire Size - Range (mm)
Stainless Steel Wire Size - Range (mm)
Aluminium Wire Size - Range (mm)
Recommended Generator (KVA)
Dimensions (mm)
Nett Weight (kg)
Price (ex GST)
Price (inc GST)

Spare Parts Ordering
To assist you in ordering your Spare Part to suit Hafco Machinery simply select from the list below, if your part is not listed below please view “Parts List PDF” to identify your part required (if provided) then simply click the "SEND PARTS REQUEST" Button and fill in the required details. Our Spare Parts and Service Department will contact you as quickly as possible. If you need further assistance please contact us.
