HAFCOHF-35
Portable Magnetic Drill
  • 1 of 7
    D950
  • 2 of 7
    Control Panel
  • 3 of 7
    Right Side View
  • 4 of 7
    Drill Chuck
  • 5 of 7
    Shown with Optional Broach Cutter
  • 6 of 7
    Carry Handle
  • 7 of 7
    Durable Plastic Case
Order Code: D950
HF-35 - Portable Magnetic Drill (240V)
Ø35mm Drill Capacity
Manual Feed
HAFCO
ORDER CODE
D950
MODEL
HF-35
Feed
Manual
Drilling Capacity Range - Manual (mm)
12 - 35
Maximum Thickness (mm)
50
Suits Cutter Shank Size (mm)
19
Number of Drilling Speeds (No.)
1
Full Load Drilling Speeds (rpm)
350
No Load Drilling Speeds (rpm)
620
Magnetic Holding Power (kg/f)
1529
Motor Power (kW / hp)
1.1 / 1.46
Voltage / Amperage (V / amp)
240 / 10
Nett Weight (kg)
17.5
Description
Manufactured in Taiwan

Hafco Magnetic base drills are designed to meet productivity & safety expectations

On-site hole cutting in steel plates, H-Beams shaped bars, framework, ship building, bridge construction and repair, steel reinforcements, and many other metal working and construction jobs.

NOTE: Shown with optional broach cutter
Features
  • Compact design with heavy duty magnet
  • Drills up to 35mm diameter through 50mm plate
  • Sturdy feed handles
  • Includes drill chuck and adaptor for use of twist drills up to 12mm diameter
  • CE approved
Includes
  • Coolant tank kit
  • Safety chain
  • 13mm drill chuck and adaptor
  • Blow mould plastic case
Product Brochure

Instructions Manual
6.33 MB
