THIS PRODUCT IS NO LONGER AVAILABLE. Click to see recommended item > W1645 (Razor ARC 180DC)
UNIMIGARC 170DC
DC TIG & ARC Inverter Welder
  • 1 of 4
    W164
  • 2 of 4
    Parts
  • 3 of 4
    Carry Case
  • 4 of 4
    Right View
Order Code: W164
ARC 170DC - DC TIG & ARC Inverter Welder (240V)
10-170A
#KUMJR170
UNIMIG
ORDER CODE
W164
Type
DC Inverter Welder
MODEL
ARC 170DC
Part Number
#KUMJR170
Voltage / Amperage (V / amp)
240 / 15
Recommended Plug (amp)
15
Ieff Current (amp)
15 amp
Rated Output Current
170 amp / 26.8V

10 - 170 amp
No Load Voltage (V)
80
Duty Cycle 40 Deg C - TIG (% @ amp)
35%@170A, 100%@100A
Duty Cycle 40 Deg C - MMA
25%@170A, 100%@85A
Recommended Generator (kVA)
7.7
Efficency (%)
85
Power Factor
0.7
Insulation Class
F
Dimensions (mm)
320 x 120 x 210
Nett Weight (kg)
5.2
Description
The Arc170 is an inverter-based welding machine produced using the latest in IGBT technology. Low cost and portable this machine is reliable, robust and stacked with features that you can expect from a quality welder.

The DC MMA welding capability delivers a smooth and incredibly stable arc allowing easy welding with electrodes producing high quality welds including cast Iron, stainless and low hydrogen.

The Arc170 is equipped with DC Lift Arc function, connection of the 17V Tig torch allows quality DC Tig welding of steel, stainless steel, bronze and copper. The Lift Arc function is superb and delivers perfect arc ignition every time without any sticking of the tungsten electrode to the work piece, a remarkably smooth stable arc produces high quality Tig welds.

The Arc170 is an exceptional machine that is suitable for a wide range of applications including light industrial use, site welding, farming, along with repair and maintenance applications.

The Arc170 has the option of being packaged in a tough PVC carry case with your choice of MMA option accessories or MMA/TIG option accessories. The Arc170 gives you the best of both worlds - great portability, with the power to get the job done.

Built to our specification and manufactured in compliance to AS/NZ60974.1
Features
  • Latest IGBT inverter technology

  • MMA
  • Hot start (improves electrode starting)
  • Arc force (boosts current to prevent electrode extinguishing)
  • Excellent arc stability with all electrodes

  • DC TIG
  • Lift arc ignition (prevents tungsten sticking during arc ignition)
  • Ultra smooth DC TIG welding current

  • Thermal overload protection
  • IP21S rating for environmental/safety protection
  • Generator compatible (recommend 8.0 KVA minimum)
  • Tolerant to variable supply power
Includes
  • Arc 170 Amp MMA/TIG Welding Inverter
  • Shoulder Strap
  • PVC carry case
  • 4M ARC Welding lead set 35-50mm Dinse style connections
  • Arc & earth leads
Optional Accessories
  • REG - Twin Gauge Argon Regulator
  • 17V TIG Welding Torch - 17V 4 & 8 Metre Air Cooled TIG Welding Torch
  • 4 Metre 16mm Lead Set 10/25 Connector
