THIS PRODUCT IS NO LONGER AVAILABLE. Click to see similar products > Welding Helmets
TECMENTEC-3G
Auto Darken Welding Helmet
  • 1 of 7
    W013
  • 2 of 7
    Controls
  • 3 of 7
    Front View
  • 4 of 7
    Left View
  • 5 of 7
    Inside Helmet
  • 6 of 7
    Inside Helmet
  • 7 of 7
    Adjustment Nob
Order Code: W013
TEC-3G - Auto Darken Welding Helmet
5~8 / 9~13 Shade
Includes Grinding & Oxy Function
TECMEN
ORDER CODE
W013
MODEL
TEC-3G
Viewing Area (mm)
95 x 62
Cartridge Size (mm)
110 x 90 x 9
Arc Sensors (No.)
4
Light State
DIN 3.5
Shade
DIN 5 ~ 8, 9 ~ 13
Shade Control
External Variable Shade
Power On/off
Fully Automatic
Sensitivity Control
Adjustable Dial Knob
UV/IR Protection
UpDIN 16
Helmet Power Supply
Solar Cell, Battery Change

Required (1 x CR2450

lithium battery)
Switching Time Light To Dark
1/25,000 Second
Delay Time Dark To Light (Seconds) (sec)
0.1 ~ 1.0 (via Dial)
TIG Rated Minimum (amp)
2
Grinding Function (Yes / No)
Operating Temperature (ºC)
-10ºC ~ 55ºC
Storing Temperature (ºC)
-20ºC ~ 70ºC
Helmet Material
High Impact

Resistant Nylon
Total Weight (g)
445
Application Range
Stick, Mig, Tig, Arc Welding,

Grinding, Plasma &

Oxy Cutting
Standard
AS/NZS 1338.1.1992
Features
  • Suitable for MIG, TIG, Plasma, Arc welders, Grinding & Oxy cutting
  • Adjustable shade from 5 to 13 with grinding function
  • Viewing area 95 x 62mm
  • Automatic activation in 1/25,000 second
  • Solar powered with 4 arc sensors, (inc. 1 x CR2450 lithium battery)
  • Adjustable sensitivity dial
  • Adjustable delay time dial
  • Protects from UV and IR radiation
  • Light weight high impact resistance nylon
  • AS/NZS 1338.1.1992
Includes
  • Includes 1 x additional lens cover & sweatband
