PD-35 Pedestal Drill
  • 1 of 12
    K8783
  • 2 of 12
    Magnetic Switch and Safety Stop Switch
  • 3 of 12
    Safety Stop Switch
  • 4 of 12
    Safety Micro Switch on Belt Cover
  • 5 of 12
    Adjustable Safety Chuck Guard
  • 6 of 12
    Tilting and Rotating Cast Iron Table
  • 7 of 12
    Quill Handle
  • 8 of 12
    B Section Belt Drive System
  • 9 of 12
    Drilling Depth Stop Setting with Scale
  • 10 of 12
    Motor and Belt Tension Lever and Lock
  • 11 of 12
    13mm Keyless Drill Chuck (C292)
  • 12 of 12
    3MT x JT6 Drill Chuck Arbor (D443)
Order Code: K8783
QLD Schools / TAFE - PD-35 Pedestal Drill (415V)
31.5mm
QLD Contract Item No.26
HAFCO METALMASTER
ORDER CODE
K8783
QLD Contract No.
QLD Item No.26
Model
Schools / TAFE PD-35B
Bench / Pedestal Type
Pedestal
Duty Type
Industrial-Duty
Drill Capacity
31.5mm
Spindle Taper
3MT
Spindle Travel
125mm
Throat Depth
225mm
Quill Diameter
72mm
Collar Diameter
92mm
Column Diameter
92mm
Spindle To Table
730mm
Spindle To Base
1175mm
Table Shape
Square
Table Size
350 x 350mm
Micro Switch On Pulley Guard
Spindle Drive Type
B Section Belt
Spindle Steps No.
18
Spindle Speeds
90-1680rpm
Motor Power
0.75kW / 1hp
Motor Voltage
415V
Overall Height
1700mm
Weight (nett)
136kg
Description
We for many years have been working in close consultation with education departments to ensure the most suitable equipment is provided to our schools and TAFE, not only does it comply with the departments stringent safety requirements but is built to last the distance. That's why we consider our company to be a specialist when it comes to supplying quality Wood Work and Metal Working Machinery for Public or Private Schools, TAFE Colleges and Trade Training Centres in all states of Australia.
Features
  • Ideal for industrial workshop use
  • Quiet "B" section V-belt drive system
  • Quick action belt tensioning lever
  • Adjustable safety drilling chuck guard with swivel screen
  • Safety micro switch on belt cover
  • Safety magnetic-type switch
  • Emergency stop switch
  • Rack & pinion table height adjustment with locking lever
  • Thick walled column ensuring greater rigidity
  • Table tilts left & right to 45º & rotates 360º
  • Drilling depth stop setting with scale
  • T slotted work table
  • 2 speed high /low switch
  • 18 Spindle speeds, 90-180, 150-300, 160-320, 215-430, 240-480, 310-620, 525-1050, 600-1200, 840-1680rpm
  • Fan-cooled 415 volt motor rated for continuous use with overload protection
  • Includes heavy duty cabinet stand
Includes
  • 13mm Keyless Drill Chuck (C292)
  • 3MT x JT6 Drill Chuck Arbor (D443)
