THIS PRODUCT IS NO LONGER AVAILABLE. Click to see similar products > Wood Lathes
OMEGA STUBBY S750 Wood Lathe
  • 1 of 13
  • 2 of 13
    CH100 Roughing Gouge 19mm (R8135)
  • 3 of 13
    CH200 Spindle Gouge 6.35mm (R8137)
  • 4 of 13
    CH220 Spindle Gouge 12.7mm (R8139)
  • 5 of 13
    CH300 Skew Chisel Standard 12.7mm (R8140)
  • 6 of 13
    CH500 Parting and Beading 3.17mm (R8142)
  • 7 of 13
    CH700 Domed Scraper Chisel 12.7mm (R8151)
  • 8 of 13
    CH702 Domed Scraper Chisel 25.4mm (R8153)
  • 9 of 13
    Drive & live Centres (WC037 & WC023)
  • 10 of 13
    4 Jaw Scroll Chuck (W370)
  • 11 of 13
    Adaptor (W366)
  • 12 of 13
    Curved Tool Rest (W290B)
  • 13 of 13
    Face Plate 200mm (W290C)
Order Code: K8123
Schools / TAFE - OMEGA STUBBY S750 Wood Lathe (415V)
400 x 850mm
Schools / TAFE S750
Swing Over Bed
Between Centres
Spindle Taper
Spindle Thread
M30 x 3.5mm
Motor Power
1.5kW / 2hp
Weight (nett)
We for many years have been working in close consultation with education departments to ensure the most suitable equipment is provided to our schools and TAFE, not only does it comply with the departments stringent safety requirements but is built to last the distance. That's why we consider our company to be a specialist when it comes to supplying quality Wood Work and Metal Working Machinery for Public or Private Schools, TAFE Colleges and Trade Training Centres in all states of Australia.
  • A short-bed wood lathe on which you can also turn spindle work
  • Heavy duty cast iron construction for less vibration and longer life
  • Height-adjustable stand
  • A 270kg heavyweight lathe which is modular. It can be assembled and disassembled quickly and moved by two people
  • Headstock to base alignment controlled by machined keyways for accurate alignment
  • Patented sliding and rotating bed
  • Sliding the bed out allows you to work with various size material. Ability to turn platters, bowls or hollow-forms up to 30" in diameter and turn spindles up to 30" long
  • Unique auxiliary bed attaches to the machine in five different locations with several orientations. This allows great flexibility
  • 2hp 415V motor
  • Ø200mm Face plate
  • 2MT Live centre
  • 2MT Spur Centre,
  • Left hand tool slide
  • Right hand tool slide
  • 300mm Tool rest
  • Universal bowl bed
  • Self eject tail centre
  • 24 Hole indexing attachment
  • Vacuum port
  • Remote stop/start & magnetic base
  • Curved tool rest
  • Scroll chuck
  • Set of HSS Chisels

Product Brochure
Instruction Manual
608.88 KB
Spare Parts Ordering
To assist you in ordering your spare part quicker than ever before, we have listed our most common spare parts to suit our Hafco Machinery for purchase online. Just choose between the 2 options outlined below, to find exactly what you are looking for. If you need further assistance please contact us.
Option 1
Browse through the "Common Spare Parts" tab below . Once you have identified your part, you can add it to your cart by clicking on the "+ ADD TO CART" button. If you wish to add multiples of this part you can either click the "+ ADD TO CART" button as many times as you like or click on the "VIEW CART" button and change the order quantity, prior to completing your order.
Option 2
If your part is NOT listed in the "Common Spare Parts" tab below , click the "MORE INFO" button to complete the "Spare Parts Enquiry Form".
This will provide you with the option to email your spare part enquiry direct to our Spare Parts and Service Department, or if you wish, you can download a printable version of this enquiry form which will include a copy of the Parts List to suit this machine (if available). Further instructions for the return email address or fax number of this printable form is provided on the document for your convenience.
NOTE: Please remember to clearly identify your part on the included parts diagram if necessary so that we can respond as quickly as possible with a price and availability for the part(s) you require.
