HAFCO METALMASTEREB-280DSV
Swivel Head-Dual Mitre Metal Cutting Band Saw
  • 1 of 21
    B063V
  • 2 of 21
    Rear View
  • 3 of 21
    Swivel Head Dual Mitre
  • 4 of 21
    Control Panel
  • 5 of 21
    Adjustable Hyraulic Down Feed Control
  • 6 of 21
    Heavy Duty Hydraulic Down Feed Cylinder
  • 7 of 21
    Blade Tension Gauge
  • 8 of 21
    Ball Bearing Blade Guides
  • 9 of 21
    Ball Bearing Blade Guides and Brush
  • 10 of 21
    Blade Cleaning Brush
  • 11 of 21
    Variable Speed Motor and Gearbox
  • 12 of 21
    Sliding Vice for Dual Mitre
  • 13 of 21
    Vice
  • 14 of 21
    Dual Mitre Head with Degree Scale
  • 15 of 21
    Sliding Vice Lock
  • 16 of 21
    Swivel Head Setting Stop at 45 Degree
  • 17 of 21
    Swivel Head Setting Stop at 60 Degrees
  • 18 of 21
    Material Support with Roller
  • 19 of 21
    Material Length Stop
  • 20 of 21
    Safety Blade Guard Micro Switch
  • 21 of 21
    Coolant System
Order Code: B063V
EB-280DSV - Swivel Head-Dual Mitre Metal Cutting Band Saw (240V)
245 x 180mm (W x H) Rectangle Capacity
Electronic Variable Blade Speed 20-90mpm
HAFCO METALMASTER
ORDER CODE
B063V
Model
EB-280DSV
Operation Type
Swivel Head - Dual Mitre
Cutting Head Beam Type
Manual
Cutting Head Beam Return
Manual Return
Cutting Head Down Feed Control
Adjustable Hydraulic
Round @ 90º
225mm
Round @ 45º
160mm
Round @ 60º
100mm
Square @ 90º
180mm
Square @ 45º
160mm
Square @ 60º
100mm
Rectangle (W x H) @ 90º
245 x 180mm
Rectangle (W x H) @ 45º
160 x 160mm
Rectangle (W x H) @ 60º
100 x 100mm
Vice Clamping Fixture
Manual - Quick Action
Coolant System
Table Working Height
965mm
Blade Steps / Speeds
Variable 20-90 M/min
Blade Size (L x W x T)
2480 x 27 x 0.9mm
Motor Power
1.5kW / 2hp
Voltage
240V
Weight (nett)
315kg
Description
Manufactured in Taiwan
Features
  • 245 x 180mm rectangular capacity
  • Electronic variable blade speed, 240V motor
  • Larger cutting capacity than conventional cold saws
  • Swivel head double mitre cut to 45º right & left, 60º right
  • Quick action lock/release lever for swivel head
  • Heavy-duty gear drive system
  • Control panel mounted up high for convenient & easy access
  • Heavy duty hydraulic down feed cylinder accessible from front of machine for convenient & easy access
  • Ball bearing blade guides ensures minimal blade clearance wear and increases blade life due to less friction
  • Blade cleaning brush incorporated into blade guide system
  • Quick-action lock/release vice
  • Adjustable length stop for repetition cutting
  • Unique sliding vice design for dual mitre operation
  • Coolant system for cutting efficiency and blade life
  • Adjustable hydraulic cylinder for auto feed
  • Material support roller for long stock
  • User friendly blade tension system with gauge
  • Vibration free, low noise operation ensures clean & high precision cuts
  • Machine stand with integrated cooling fitted as standard
Product Brochure

Blade Selection Chart
381.95 KB
Trouble Shooting Guide
330.4 KB
Instruction Manual
3.83 MB
